MCX Male to MCX Male Right-Angle Coaxial Cable 50 Ohm RG316

50 Ohm RG316 RF Pigtail for Test & Measurement

Engineered for high-fidelity RF connectivity, our MCX Male to MCX Male Right-Angle Coaxial Cable is the definitive solution for space-constrained and high-performance applications. This 50 Ohm RF pigtail assembly combines the reliability of secure MCX connectors with the low-loss characteristics of flexible RG316 cable. The right-angle connector is expertly designed to reduce cable strain and allow for clean routing within compact enclosures, test benches, and embedded systems.

• Connector Types: MCX Male (Straight) to MCX Male (Right-Angle)
• Impedance: 50 Ohm for standard RF systems
• Cable Type: High-Performance, Low-Loss RG316
• Frequency Performance: Optimized for DC to 6 GHz operation
• Primary Use: RF Test, GPS, SDR, Internal Module Interconnection

• Connector: Professional Nickel Finish
• Center Pin: Gold Finish for superior conductivity
• Cable Jacket: Light Brown / Tan (Standard FEP color)

• Cable Diameter: 2.50 mm (0.098 inches)
• Standard Lengths: Available in various lengths from 10cm to 50cm

We are a direct manufacturer and can produce custom lengths to meet your exact project requirements.

• Space-Saving Right-Angle Design: The 90-degree MCX connector minimizes the cable's footprint, preventing strain and enabling tidy installation in tight enclosures.
• Superior Signal Integrity: Precision 50 Ohm impedance matching minimizes signal degradation (VSWR and Insertion Loss), crucial for sensitive measurement applications.
• Durable Construction: Features robust, nickel-plated brass connector bodies that withstand repeated mating cycles.
• High-Quality Shielded Cabling: The RG316 cable offers excellent protection against electromagnetic interference (EMI) and radio-frequency interference (RFI).

This versatile RF pigtail is designed for any device requiring a 50 Ohm MCX interface. Applications include:

• RF Test and Measurement Equipment
• Software-Defined Radio (SDR)
• GPS / GNSS Systems
• Wireless Communication Hardware
• Embedded Systems & IoT Devices

Note: Please verify that your equipment utilizes MCX series connectors before ordering.

• RoHS Compliant: Manufactured using materials that comply with the Restriction of Hazardous Substances directive.
• Quality Control: Each cable assembly undergoes a multi-point quality inspection process.

To ensure maximum performance and lifespan, avoid bending the cable tighter than its specified minimum bend radius (approx. 13mm / 0.5 in).
